BH-2500、BH-3500、BH-5500、BH-6500、BH7500、BH8500、BH10500 Power Amplifier

Quick info

This machine adopts a DSP chip with 20 frequency point levels per channel, and adopts an integrated LED dynamic module display. Each frequency point uses 8 display level signals, which can monitor the working frequency of each channel in real-time, achieving stability, visibility, and clear and convenient operation of the machine during operation.

Back to Contents

Quote Now sales1@epxunguan.com

Description
Additional Information

1.Standard 2U chassis volume.
2. This machine adopts a DSP chip with 20 frequency point levels per channel, and adopts an integrated LED dynamic module display. Each frequency point uses 8 display level signals, which can monitor the working frequency of each channel in real-time, achieving stability, visibility, and clear and convenient operation of the machine during operation.

MODEL	BH-2500	BH-3500	BH-5500	BH-6500	BH-7500	BH-8500	BH-9500
8Ω Stereo Power	2×250W	2×350W	2×500W	2×650W	2×750W	2×850W	2×1050W
4Ω Stereo Power	2×425W	2×600W	2×850W	2×1150W	2×1275W	2×1450W	2×1785W
2Ω Stereo Power	2×650W	2×1200W	2×1340W	2×1450W	2×1550W	2×1650W	2×2200W
8Ω Bridged mono output	780W	1400W	1560W	2150W	2350W	2650W	3200W
Frequency Response	20-20000Hz(±0.3dB)
THD	＜0.03% @ 8Ω 1KHz
Crosstalk	＞70dB @ 8Ω 1KHz
Input Impedance	20K Ω (Balanced)/10KΩ(Unbalance)
Input Sensitivity	0.775V/1.0V/1.4V
Protection	Overheat,short circuits,DC limited and softstart,Output relay-Zero Current Switch,Smart Clip limiter.
Height	2U	2U	2U	2U	2U	2U	2U
