Home > Products > Wireless microphone > 2CH > RIY-0317 2CH Wireless Microphone

RIY-0317 2CH Wireless Microphone

MOQ: 10pcs

Back to Contents

Quote Now sales1@epxunguan.com

Model	RIY-0317
Oscillation mode	PLL frequency synthesis
Frequency range	UHF499MHz-900MHz
Frequency stability	±0.001%
Modulation mode	FM
SNR	>60dB
Distortion	<0.5%@1KHz
Receiver sensitivity	1.2/UV @S/N=12dB
Power supply	DC 12V
Audio output	Independent 0-2V2/Hybrid 0-2V
Power supply	DC 3V(1.5V AA×2)
Microphone power consumption	110mA
Carrier frequency	UHF499MHz-937MHz
Frequency stability	±0.001%
Max frequency offset	±70KHz
SNR	>60dB
Adjacent frequency interference ratio	>80dB
Dynamic range	≥100dB
Type	Dynamic
Polarity mode	Cardioid
Frequency response	60Hz-17KHz
Microphone sensitivity	-42±2dB@1KHz
