● 1. Balanced microphone input
● 2. Each segment has -20db attenuation for easy adjustment of music quality
3. Three equalizers per channel to create warm sound
● 4. Equipped with auxiliary sending, auxiliary returning, monitoring, and recording functions
● 5. Master control 2 × 7-segment equalization
6. Using 16 types of digital display digital effectors
● 7. MP3 large display player with SD card socket
8. Complete built-in protection functions, with a power of 4 Ω 350Wx2
● 9.6/8/12/16 mono microphone input
| Model |
PMX-608 |
PMX-808 |
PMX-1208 |
PMX-1608 |
| Channel EQ |
3 BAND |
| AUX Output |
1 |
| Return |
1 |
| EFFECT |
16/99 effect |
| Main EQ |
7 BAND |
| Main OUT |
1 Stereo |
| Total harmonic distortion |
< -0.1 % |
| Frequency response |
20Hz-20KHz +1 dB /-3dB |
| S/N |
-75db |
| Resi dual output noise |
<-80dBu |
| Gain control |
MIC 35dB(20dB-60dB) Line 20dB(20dB-60dB) |
| Hea dphone output power |
150mW(1 KHz,THD=0.5%,200 Ω |
| Maximum output level |
18dBm(1KHz,THD=0.5%) |
| Power consumption |
35W |
